Name: Festo Connector NPQHDQ10EP10 Pneumatic Tube Fittings 578326
Brand: FESTO
Price: 1 USD

Brand Name : FESTO

Model Number : NPQH-D-Q10-E-P10

Place of Origin : China

MOQ : 1 PCS

Price : EXW USD3-5

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 2000 pcs per week

Delivery Time : 7-10 working days

Packaging Details : plastic bag, carton

Specifications : NPQH-D-Q10-E-P10

Order no : 578326

Brand : FESTO

Size : Standard

Size of pack : 10

Product weight : 23 g

Contact Now

Festo Connector NPQH-D-Q10-E-P10 578326 Pneumatic Tube Fittings

About product

All metal push-in fitting made of chemically nickel-plated brass

High corrosion resistance CRC3 and chemical resistance

For pneumatic applications with a temperature range up to 150 °C and a pressure range up to 20 bar.

Product Technical Data

Size	Standard
Nominal size	9 mm
Tubing insertion depth	18.3 mm
Design	Straight design
Size of pack	10
Design	Push-pull principle
Symbol	00997424
Corrosion resistance class CRC	3 - high corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Cleanroom class	Class 4 according to ISO 14644-1
Ambient temperature	0°C-150°C
Product weight	22.8 g
Pneumatic connection, port 1	For tubing outer diameter of 10 mm
Pneumatic connection, port 2	For tubing outside diameter of 10 mm
Note on materials	RoHS-compliant
Material housing	Brass, chemically nickel-plated
Guard ring material	PEI
Material release ring	Brass, chemically nickel-plated
Material tubing seal	FPM
Material tubing clamp component	High-alloy stainless steel
Thrust ring material	PEI

General technical data

Festo Connector NPQH-D-Q10-E-P10 Pneumatic Tube Fittings 578326

There are so many models.Welcome to enquiry !
