Aluminium Hydraulic Dump Truck Controls Pressure Relief Valve 80 I/min

Product Categories

Airwolf Automation

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Place of Origin : China

Brand Name : FLY

Certification : CE

Model Number : VMP-80,LP80

MOQ : 1Piece

Price : USD 22-36

Packaging Details : Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement

Delivery Time : within 1-30 working days after payment

Payment Terms : T/T , paypal, Western Union

Supply Ability : 10000pcs

Contact Now

Aluminium Hydraulic Dump Truck Controls Pressure Relief Valve 80 I/min

Sheet Data

Luce nominale DN Rated size	11
Portata max 1/min—GPM Max flow-rate	80 - 21
Pressione di lavoro max Max working pressure	450 bar 6525 PSI
Pressione max di taratura Max setting pressure	350 bar 5075 PSI
Rapporto di pilotaggio Pilot ratio
Temperatura ambiente °C Room temperature	-30 +50
Temperatura olio °C Oil temperature	-30 +80
Filtraggio consigliato micron Filtration	30 - 50
Coppia di serraggio Tightening torque
Peso Weight kg

Aluminium Hydraulic Dump Truck Controls Pressure Relief Valve 80 I/min
